FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 113 of 170
BSI-Base Commands and Responses:
A
Read all weight data immediately
B
Read Gross weight value immediately
C
Clear the tare
G
Read voltage value of DC power supply
I
Read current weight (indicated) value immediately
P
Read the current stable weight value
Q
Load set point values
R
Read set point values
S
Read Status
T
Tare
U
Read digital inputs
V
Read digital outputs
W
Set/Reset digital outputs
X
Read current weight value in increased resolution immediately
Z
Zero
BSI-BASE Command Table:
Description
Command
Response
Read all weight data
immediately
[ADR][A]
[ADR][A][STATUS][SIGN][NET W]
[SIGN][TARE W] [SIGN] [GROSS W]
Read Gross weight value
immediately
[ADR][B]
[ADR][B][STATUS][SIGN][WEIGHT
VALUE]
Clear the tare memory
[ADR][C]
[ADR][C][A]
Read voltage value of DC
power supply
[ADR][G]
[ADR][G][STATUS][VOLTAGE VALUE]
Read current weight
(indicated) value immediately
[ADR][I]
[ADR][I][STATUS][SIGN][WEIGHT
VALUE]
Print: Read the stable weight
[ADR][P]
[ADR][P][STATUS][SIGN][WEIGHT
VALUE]
Load set points
[ADR][Q][SP
No][L][SIGN][SP VALUE]
[ADR][Q][STATUS]
Read set points
[ADR][R][SP No][L]
[ADR][R][STATUS][SIGN][SP VALUE]
Read Status
[ADR][S]
[ADR][S][STATUS-1][STATUS-2]
[STATUS-3]
Tare
[ADR][T]
[ADR][T][STATUS]
Read digital inputs
[ADR][U]
[ADR][U][STATUS][Inputs]
Read digital outputs
[ADR][V]
[ADR][V][STATUS][Outputs]
Set/Reset digital outputs
[ADR][W][Outputs]
[ADR][W][STATUS]
Read weight value in
increased resolution
[ADR][X]
[ADR][X][STATUS][SIGN][WEIGHT
VALUE]
Zero
[ADR][Z]
[ADR][Z][STATUS]
BSI-PRO Commands and Responses:
Description
Command
Response
ID1 name and data write
DA 1 [16d name ] [32 digit data]
DAA
ID2 name and data write
DA 2 [16d name ] [32 digit data]
DAA
ID1 name write
DH 1 [16 digits name]
DHA
ID1 data write
DI 1 [32 digits data]
DIA
ID2 name write
DH 2 [16 digits name]
DHA
ID2 data write
DI 2 [32 digits data]
DIA
ID1 name and data read
DK 1
DKA [16d name ] [32 digits data]
ID2 name and data read
DK 2
DKA [16d name ] [32 digits data]
Write SmartAPP and apply
DB+[8 digits Limit-1]+[8d Limit-2]
+[8d Limit-3]+[8d Limit-4]+[8d Limit-
5]+[8d Limit-6]
DBA
