Topology
100% free choice of star, tree, ring or daisy chain
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45
connectors.
Isolation
Galvanically isolated bus electronics
Response speed
Min. 4 ms response delay after read/write commands
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
CC-Link IE Field (optional)
Data rate
1 Gbit/s Baud Rate
CSP+ file
Generic CSP+ file provided
Topology
Line, Star, Line/Star mixture or Ring topology depending on physical media
Installation
IEEE802.3 1000Base-T cable, ANSI/TIA/EIA-568-B (Category 5e) compliant 4-
pair, balanced-type shield cable, Double-shield type is recommended.
Max. number of
networks
Up to 239
Number of connected
nodes per network
Master station = 1, Slave station = 120
Isolation
Galvanically isolated bus electronics
Response speed
Up to 4 ms. response delay after read/write commands.
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
Power Consumption
FT-112
Panel
12 – 28 VDC 250 mA + max. 500 mA for fieldbus interfacing
FT-112 (D)
Panel
12 – 28 VDC 150 mA + max. 500 mA for fieldbus interfacing
+ load cell currents.
Environment and Enclosure:
Operation temp. range
Approved scales -10 °C to +40 °C
Industrial usage -15 °C to +55 °C
Humidity
80% RH max, non-condensing
Enclosure
Stainless steel front panel and rear panel, aluminum body.
Protection
Front panel IP67
Panel cut size
186 x 92 mm
(7.32 x 3.62”)
Sizes ( W x H x D )
205 x 108 x
112,5mm
(8.07 x 4.25 x 4.43”)
Weight
1,4 kg
(3,07 lb)
Packing sizes
(W x H x D)
273 x 190 x 153 mm
(10,75 x 7,48 x 6,02”)
Weight Packed
2,5 kg
(5,51 lb)
