FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 120 of 170
13.2.1 Modbus Data Structure
Modbus RTU and TCP/IP Command Table;
Address
R/W
Word
Command
Definition
40001
R
2
Actual weight (Net if the indication is in Net, Peak value or Hold value)
40003
R/W
2
Tare weight
40005
R
2
Gross weight
40007
R
2
Status
Bit
Definition
B0
0 – Dynamic is inactive
1 – Dyn weight is calculating
B1
0 – Weight is actual w.
1 – Weight is dynamic result
B2
0 – Weight is Stable
1 – Weight is unstable
B3
0 – Gross mode
1 – Net mode
B4
0 – Preset tare is passive
1 – Preset tare is active
B5
0 – Not power on zeroed
1 – Zeroed with pwr on zero
B6
0 – First Unit (power on)
1 – Second Unit
B7-B10
Not used
B11
0 – Key lock is passive
1 – Key lock is active
B12
0 – Out of center of zero
1 – Weight is in center of zero
B13
0 – High res. is passive
1 – High res. is active
B14
0 – Basic Peak is passive
1 – Basic Peak is active
B15
0 – Hold is passive
1 – Hold is active
B16-B26
Not used
B27
0 – None
1 – Decimal point is X.XXXX
B28
0 – None
1 – Decimal point is X.XXX
B29
0 – None
1 – Decimal point is X.XX
B30
0 – None
1 – Decimal point is X.X
B31
0 – None
1 – No decimal point
40009
R
2
Error
Status
Bit
Definition
B0
0 – No Error
1 – Low voltage det.
B1
0 – No Error
1 – In programming mode
B2
0 – No Error
1 – System error
B3
0 – No Error
1 – ADC under range
B4
0 – No Error
1 – ADC over range
B5
0 – No Error
1 – ADC out of range
B6
0 – No Error
1 – Tilt Switch is active
B7– B31
Not used
40011
R
2
Heartbeat for connection checking, this value is increased every
100 milliseconds.
40013
R
2
Last print value
40015
R/W
2
CN (Label number)
Refer to parameter [254], page 56
40017
R
2
Quantity of M+
40019
R
2
Total of M+
40021
R/W
4
Grand Total
Use Dword at floating point operation
40025
R/W
2
Commands
Dec
Definition
0
None
1
Zero
2
Tare
3
Clear
4
Print
5
Reprint the last label
6
High resolution enable
7
High resolution disable
