Ethernet TCP/IP
IMPORTANT NOTE: Modbus RTU and Modbus TCP interfaces require Modbus SD card at the SD2 card slot
on the rear of the instrument.
Ethernet output of FT-112(D) Panel is programmable to BSI command set, Continuous data output, Fast
continuous data output, Modbus TCP/IP High-Low, Modbus TCP/IP Low-High. The first three data structures,
as shown in the table below, are described in the related sections.
Modbus TCP interfacing.
Refer to Page 119.
Modbus TCP interfacing.
Refer to Page 119.
Table 13-1 - Ethernet output interfacing
You can communicate with FT-112(D) Panel after programming Ethernet TCP/IP and Modbus TCP related
parameters [ 15- ].
13.3.1 Ethernet Parameters
Ethernet parameters can be adjusted by keys in programming mode. Refer to parameter block [ 15- ].
Additionally, Ethernet parameters can be set up by Indface2x PC software over Local Network Area or by
Flintec´s set up PC software. Both software are available on www.flintec.com .
Note: For Modbus TCP/IP Data Structure see Table on Page 120.
Device name of the instrument. Refer to parameter 255.
Obtain IP address manually. Refer to parameter 152.
Ethernet connection port of the instrument. Refer to parameter 156.
Network point that acts as an entrance to another network.
Refer to parameter 155.
Describes IP address can be used in network. Refer to parameter 154.
Obtain primary DNS manually. Refer to parameter 159.
Obtain secondary DNS manually.
Remote Connection
Check Box
Automatic connection to any device on the network. Refer to parameter 15E
and 15F. Default is ‘Disabled’.
IP address of the PC, Printer or Device to be connected automatically.
Enter IP address of the remote device.
Ethernet connection point of PC, Printer or Device to be connected
automatically. Enter port number of the remote device.
Default password is 123456.
