FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 132 of 170
Figure 14.3 - GSDML Configuration
GSDML Configuration
Description
Input 2 word_1
1
st
Dword (FT-112(D) Panel Output to PLC Input)
Input 2 word_2
2
nd
Dword (FT-112(D) Panel Output to PLC Input)
Output 2 word_1
1
st
Dword (PLC Output to FT-112(D) Panel Input)
Output 2 word_2
2
nd
Dword (PLC Output to FT-112(D) Panel Input)
14.2.4 Profinet Data Structure
For the Data Structure for Profinet see Appendix 1, page 146
