FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 131 of 170
14.2.1 Data Format
Data format of weight value can be programmable for Floating point (IEEE 754) or Integer. Refer to parameter
[ 191 ].
14.2.2 Profinet Parameters
Ethernet parameters can be adjusted by keys in programming mode. Refer to parameter block [15-].
Additionally, Ethernet parameters can be set up by Indface2x PC software over Local Network Area or by
Flintec´s set up PC software. Both software are available on www.flintec.com .
Note: Station name is ‘scale-1’ as default.
14.2.3 GSDML Configuration
Profinet data consist of 2 pcs Input-2 words and 2 pcs Output-2 words. GSDML configuration for PLC
programmers is shown in Figure 14.3.
Figure 14.2 – Location of Hardware catalog
Parameters
Descriptions
DHCP
Dynamic Host Configuration Protocol automates network parameters if it is
enabled.
Host Name
Device name of the instrument.
Refer to parameter 196.
IP Address
If DHCP is disabled, obtain IP address manually.
Refer to parameter 192.
Gateway
If DHCP is disabled, obtain default gateway manually.
Refer to parameter 195.
Subnet Mask
If DHCP is disabled, obtain subnet mask manually.
Refer to parameter 194.
Primary DNS
If DHCP is disabled, obtain primary DNS manually.
Refer to parameter 199.
Secondary DNS
If DHCP is disabled, obtain secondary DNS manually.
Password
Default password is 123456.
