FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 137 of 170
Figure 14.6 – Configuration of module properties with EDS file
Data Length
Description
Input 2 words
1
st
Dword (FT-112(D) Panel Output to PLC Input)
Input 2 words
2
nd
Dword (FT-112(D) Panel Output to PLC Input)
Output 2 words
1
st
Dword (PLC Output to FT-112(D) Panel Input)
Output 2 words
2
nd
Dword (PLC Output to FT-112(D) Panel Input)
14.4.4 EtherNet/IP Data Structure
For the Data Structure for EtherNET/IP see Appendix 1, page 146
