Flintec FT-112 - APPENDIX 2: DATA STRUCTURE - CANOPEN; FT-112(D) Panel Output to PLC Input 2 nd Dword

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 154 of 170
322 page 58
1
NET
01101001
105
R/
W
TAREDELA
(1) (2)
Refer to par. 323 on page 58
01101010
106
R/
W
TOTAL
(1) (2)
Refer to par.
324 page 58
0
No
1
HORI
2
VERT
01101011
107
R/
W
GT ERASE
(1) (2)
Refer to par.
325 page 58
0
MRC
1
PASS
01101100
108
R/
W
OUTPUTS
(1) (2)
Refer to par.
326 page 58
0
STAB
1
IMME
01101101
109
R/
W
PEAK DIS
(1) (2)
Refer to par.
315 page 58
0
PEAK
1
LAST
2
ALL
Table 15-3 – Expanded command list
(1) Write this command after writing values to 1
st
Dword (Output) then apply this command with New CMD.
(2) To access the related value, read 1
st
Dword (Input).
Programming steps of frequent used commands
Reading a weight value:
1. Check the B12…B15 bits of ‘FT-112(D) Panel Output to PLC Input 2
nd
Dword’.
2. If there is not any error, read the weight value ( gross, net or tare ).
Zero Calibration procedure
1. Check the Bit-0 of Calibration Status. it should be '1'(set) to start adjustment.
2. Write ‘Adjust Zero Calibration’ command and apply New CMD to start Zero calibration.
3. Check the Bit-1 of Calibration Status. it is '1'(set) during zero calibration process.
4. The Bit-0 of Calibration Status changes to '1'(set) at the end of the Zero calibration.
5. If the Bit-3~Bit-10 of Calibration Status is '1'(set), check the description to understand the calibration
error.
Span Calibration procedure
1. Check the Bit-0 of Calibration Status. it should be '1'(set) to start adjustment.
2. Write ‘Adjust Span Calibration’ command after writing test weight values to 1
st
Dword, then apply this
command with New CMD to start Span calibration.
3. Check the Bit-1 of Calibration Status. it is '1'(set) during span calibration process.
4. The Bit-0 of Calibration Status changes to '1'(set) at the end of the Span calibration.
5. If the Bit-3~Bit-10 of Calibration Status is '1'(set), check the description to understand the calibration
error.
