FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 61 of 170
[
36-
DIG OUTPUTS
]
DIGITAL OUTPUTS (appears if option installed )
Press key or key again to enter this menu.
Or press key to go to the next sub-block.
[
361
OUT 1
:
NO
]
Digital output 1
Page 96, 96,
NO
S AIN
S IND
S ANE
S NET
S GRO
SPC1
SPC2
STAB
NET
ZR I
ZR G
RUN
ERRO
FBUS
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Disable
Absolute Indicated weight
Indicated weight
Absolute net weight
Net weight
Gross weight
Control mode-1
Control mode-2
Weighing is stable
Net weighing
Zero range of indicated weight
Zero range of gross weight
In usage
Error
Remote Output over Fieldbus or
BSI
Press key to select output function if you need function
different than basic setpoint output and active high level. Available
functions are shown on the weight display. Press key after
setting up the output function. Refer to Section 11.4 for details.
(only at SAIN, SIND, SANE, SNET, SGRO)
[
BAS-HI
]
BAS-HI
BAS-LO
THR-HI
THR-LO
VIN-HI
VIN-LO
:
:
:
:
:
:
Basic setpoint output, active high
Basic setpoint output, active low
Threshold, active high
Threshold, active low
Window, active high
Window, active low
[
362
OUT 2
:
NO
]
Digital output 2
Page 96, 96,
:
[
363
OUT 3
:
NO
]
Digital output 3
Page 96, 96,
:
[
364
OUT 4
:
NO
]
Digital output 4
Page 96, 96,
:
[
365
OUT 5
:
NO
]
Digital output 5
Page 96, 96,
:
[
366
ZR [d]
:
1.0
]
Zero range in XX.X division. Default is 1.0 d.
Page 104
For example: if the scale division is 0.5 kg and this
parameter entry is 1.0 division.
The output is activated if the indication is lower than
0.5 kg.
