FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 65 of 170
[
523
MAX
:
]
M
Scale capacity Max and division (d)
MAX1/d1
MAX2/d2
MAX3/d3
Enter scale capacity and division after press key.
Capacities and divisions of MR and MI scales are
entered as Max1, d1, Max2, d2, Max3, d3.
[
524
OVER
:
9d
]
M
Limit of Indication
NO
1d
5d
9d
2%
5%
:
:
:
:
:
:
Over indication after Max
1 division more than Max
5 division more than Max
9 divisions more than Max
2% more than Max
5% more than Max
[
525
TARETYPE
:
SUB
]
M
Tare type.
SUB
ADD
:
:
Subtractive tare. Taring reduces the maximum net.
Additive tare. Taring is limited to Max Tare and Net
weighing is done up to Max.
[
526
MAXTARE
:
0.0
]
M
Maximum tare at additive tare.
Enter the maximum tare of the scale which is written
on the marking label as;
T= + XXXX.X at additive tare
Default is 0.0 which means no limit.
53-
DLC SETUP
]
DIGITAL LOAD CELL SETUP (Only FT-112D)
Press key or key again to enter this menu.
Or press key to go to the next sub-block.
[
532
QUANTITY
:
01
]
M
Quantity of digital load cell
Enter the quantity of DLC used in the scale.
The quantity can be entered between 1 and 30.
[
533
ADDRESSING
]
M
Addressing of digital load cells
Enter serial number after press key.
[
54-
SHIFT ADJUST
]
SHIFT / ECCENTRICITY ADJUSTMENT (Only FT-112D)
Press key or key again to enter this menu.
Press key to return to beginning of the sub-block or press
key to enter the next main-block.
[
541
METHOD
:
CELL
]
M
Adjustment method
CELL
PAIR
:
:
Individual load cell shift adjust
Sectional pair shift adjustment
[
542
AUTO
ADJUST
]
M
Automatic Eccentricity Adjustment
The eccentricity correction of scale is performed automatically
[
543
MANUAL ADJUS
]
M
Manual Adjustment
The eccentricity correction of scale is performed manually.
[
544
SET TO 1
:
NO
]
M
Temporarily set shift constants to 1
NO
YES
:
:
Normal operation
(entered shift constants are used).
Test mode (shift constants are equal to 1).
