FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 80 of 170
10.1.1 Product Limit values at Classifying
The entry type can be selected as a weight value, deviation from target or percentage of the target,
parameter 312. This selection defines the set values’ entry names as shown below;
Entry type
Target
Lowest Limit
-T2
Low limit
-T1
High limit
+T1
Highest
Limit
+T2
Unloaded
scale limit
Value
TARGET
- - LOW
-LOW
+HIGH
++HIGH
EMPTY
Deviation
TARGET
- - TOL
-TOL
+TOL
++TOL
EMPTY
Percent %
TARGET
- - TOL
-TOL
+TOL
++TOL
EMPTY
The target (nominal value), low, high and empty range entries should be entered the weight value in unit;
Tolerance entries should be entered as deviation from nominal weight in unit or in percentage.
The descriptions below are considered the value entry type. Follow the similar way for entry types deviation or
percentage.
The nominal and limits values entry
1. Press the key.
2. The current target value appears on the display as [ TARGET 1250 kg ]. Enter the new value with
numerical keys. Press the key to save it or press key to return operation without saving.
3. The lowest tolerance prompt [ --LOW : 1234.6 ] will show you the current value. Enter new value
with numerical keys. Press the key to save it or press key to return operation without
saving.
4. The [ -LOW: 1245.6 ] prompt will show you the current low tolerance. Enter new value with
numerical keys. Press the key to save it or press key to return operation without saving.
5. The [ +HIGH: 1255.6 ] prompt will show you the current high tolerance. Enter new value with
numerical keys. Press the key to save it or press key to return operation without saving.
6. The [ ++HIGH: 1260.0 ] prompt will show you the current highest tolerance. Enter new value with
numerical keys.
7. The [ EMPTY : 100,0 ] prompt will show you the current empty range of the platform. Enter new
value with numerical keys.
8. Press the key to return the operation after saving the entry or press key to return operation
without saving.
Product record into SET memory
1. Press key for more than 2 seconds. [ MEMORY ] prompt appears.
2. Press key. The last used Set memory code appears [ SET :001 ].
3. Enter the new memory code by pressing the numerical keys and press key.
4. The target value is shown on the display as [ SET 001: TARGET ], [ 1250 kg ]. Enter the new
target with numerical keys and press the key.
5. The lowest tolerance prompt [ --LOW : 1234.6 ] appears. Enter new value with numerical keys and
press the key.
6. The low tolerance prompt [ -LOW : 1245.6 ] appears. Enter new value with numerical keys and
press the key.
7. The high tolerance prompt [ +HIGH : 1255.6 ] appears. Enter new value with numerical keys and
press the key.
8. The highest tolerance prompt [ ++HIGH : 1260.0 ] appears. Enter new value with numerical keys
and press the key.
9. The [ EMPTY : 100,0 ] prompt appears on the display. Enter new value with numerical keys.
10. Press the key to go to the following memory after saving it or press key to return operation
without saving.
