Working with measurement tools12
Note
• You can set up a difference calculation when previewing an image or when editing an
image in the archive.
• Depending on the camera model, you can also set up a difference calculation when
defining user presets or by selecting the measurement tool Hot spot - Spot.
• This procedure assumes that you have previously laid out at least one measurement
tool on the screen.
Follow this procedure:
1. To set up a difference calculation, do the following:
• If you are defining user presets, select
(Add measurement) and then select
(Add delta).
• If you are editing an image in the archive, select
(Measurement) and then se-
lect
(Add delta).
2. Push the navigation pad. This displays a dialog box where you can select the meas-
urement tools that you want to use in the difference calculation. You can also select a
fixed-temperature reference.
3. Push the navigation pad. The result of the difference calculation is now displayed on
the screen.
12.8 Setting a measurement alarm
12.8.1 General
You can make the camera trigger an alarm when certain measurement conditions are
met.
12.8.2 Types of alarm
You can choose between the following alarm types:
• Above: Triggers an alarm when the temperature is above the preset alarm
temperature.
• Below: Triggers an alarm when the temperature is below the preset alarm
temperature.
12.8.3 Alarm signals
When an alarm is set, the symbol
is displayed in the result table.
When an alarm is triggered, the value in the result table is displayed in red (above alarm)
or blue (below alarm) and the symbol
(above alarm) or (below alarm) is blinking.
You can also set an audible alarm (there will be a “beep” when the alarm is triggered).
12.8.4 Procedure
There are different procedures for setting up an alarm for a spot, for a box or circle, and
for a difference calculation.
12.8.4.1 Setting up an alarm for a spot
Follow this procedure:
1. To select the spot, touch the tool on the screen. The tool is now displayed with a
frame.
2. Push the navigation pad—or touch and hold the tool. This displays a context menu.
#T810587; r. AA/74078/74713; en-US
65
