FLIR E96

To Next Page

To Previous Page

Handling the camera

7.11.1 Mounting the hand strap

1. Fit the upper part of the hand strap into the bracket.

2. Fit the bracket in place on the camera and tighten the screw with the supplied Torx

key.

#T810587; r. AA/74078/74713; en-US
