Technical data22
Power system
Battery type Rechargeable Li ion battery
Battery voltage 7.2 V
Battery capacity 4.4 Ah
Battery operating time
> 3 hours at 25°C (+77°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
bay charger
Charging time 2.5 h to 95% capacity, charging status indicated by
LED's
External power operation
AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
vehicle (cable with standard plug, optional)
DC operation 10.8 to 16 V DC, polarity protected (proprietary
protected)
Power 8.5 W typically
Start-up time Typically 8 min. @ 25°C (+77°F)
Environmental data
Operating temperature range –20°C to +40°C (–4°F to +104°F)
Storage temperature range –30°C to +60°C (–22°F to +140°F)
Humidity (operating and storage) IEC 68-2-30/24 h 95% relative humidity +25°C to
+40°C (+77°F to +104°F) (2 cycles)
Directives
• 73/23EEC
• 2004/108/EC
• 2002/95/EC
• 2002/96/EC
EMC
• EN61000-6-4 (Emission)
• EN61000-6-2 (Immunity)
• FCC 47 CFR Part 15 class A (Emission)
• EN 61 000-4-8, L5
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration
2 g (IEC 60068-2-6)
Safety Power supply: EN/UL/IEC 60950-1
Physical data
Camera weight, excl. lens and battery 1.94 kg (4.27 lb.)
Camera weight, incl. lens and excl. battery 2.24 kg (4.94 lb.)
Camera weight, incl. lens and battery 2.48 kg (5.47 lb.)
Battery weight 0.24 kg (0.52 lb.)
Camera size, excl. lens (L × W × H) 284 × 169 × 161 mm (11.2 × 6.7 × 6.3 in.)
Cameras size, incl. lens (L × W × H) 306 × 169 × 161 mm (12.0 × 6.7 × 6.3 in.)
Battery size (L × W × H) 141 × 47 × 28 mm (5.5 × 1.8 × 1.1 in.)
Battery charger size (L × W × H) 158 × 122 × 25 mm (6.2 × 4.8 × 1.0 in.)
Tripod mounting
UNC ¼"-20
Housing material Aluminum, magnesium
Grip material TPE thermoplastic elastomers
#T559157; r. AH/45951/45951; en-US
115
