FLIR GF3 Series User Manual

Achieving a good image14
Reflected appa-
rent temperature
+20°C (+69°F)
Relative humidity 50%
Atmospheric
temperature
+20°C (+69°F)
14.9.4 Procedure
Follow this procedure to change the object parameters globally:
1. Turn the mode wheel to
or .
2. Push the
button to display a menu.
3. Move the joystick left/right to go to the Edit tab.
4. Move the joystick up/down to select Object parameters.
5. Push the joystick to display a dialog box.
6. Move the joystick up/down to select the parameter you want to change, then push the
joystick.
7. Move the joystick up/down to change the value, then push the joystick.
8. Push the
button to confirm and leave the setup mode.
Note
• Of the seven parameters above, emissivity and reflected apparent temperature are the
two most important to set correctly in the camera.
• To change object parameters locally, first select a measurement tool in the toolbox, then
select Use local parameters. Change the local parameters by selecting Edit local pa-
rameters, then edit them in the same way as for global object parameters.
14.9.5 Related topics
• For in-depth information about parameters, and how to correctly set emissivity and re-
flected apparent temperature, see 32 Thermographic measurement techniques.
#T559157; r. AH/45951/45951; en-US
42
