Working with views and images17
3. You can now do one or more of the following tasks before you save the image. Move
the joystick to go to a task and push the joystick to select the task.
• Select
to edit measurement tools.
• Select
to adjust the image.
• Select
to add a digital photo to the image. You turn on the digital camera
lamps by pushing the joystick. Push the
button to take a digital photo.
• Select
to delete the image.
• Select
to save the image.
17.2 Opening an image
17.2.1 General
When you save an image, you store the image on an SD Memory Card. To display the im-
age again, you can open it from the SD Memory Card.
17.2.2 Procedure
Follow this procedure to open an image:
1. Turn the mode wheel to
to enter archive mode. This displays the archive overview
or an image at full size.
2. In the archive overview, you can do the following:
• Move the joystick up/down/left/right to select the image you want to view.
• Push the joystick. This displays the selected image at full size.
3. When an image is displayed at full size, you can do the following:
• Push the joystick or the
button to edit the measurements, adjust the image, or de-
lete the image. This displays a menu.
• Move the joystick left/right to view the previous/next image.
• Move the joystick up to return to the archive overview.
4. To leave the archive mode, turn the mode wheel and select another mode.
17.3 Changing settings related to image
presentation
17.3.1 General
In live mode, you can enable/disable a variety of settings relating to image presentation.
These settings include:
• Zoom, i.e., zoom into or out of images.
• Hide/show graphics, i.e. hide or show the on-screen graphics.
• Change the color palette, i.e. the colors that are used to display the temperatures in the
infrared image.
#T559157; r. AH/45951/45951; en-US
61
