Technical data22
Power system
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
bay charger
Charging time
2.5 h to 95% capacity, charging status indicated by
LED's
External power operation AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
vehicle (cable with standard plug, optional)
DC operation 10.8 to 16 V DC, polarity protected (proprietary
protected)
Power 8.5 W typically
Start-up time Typically 7 min. @ 25°C (+77°F)
Environmental data
Operating temperature range –20°C to +50°C (–4°F to +122°F)
Storage temperature range –30°C to +60°C (–22°F to +140°F)
Humidity (operating and storage) IEC 68-2-30/24 h 95% relative humidity +25°C to
+40°C (+77°F to +104°F) (2 cycles)
Directives
• 73/23EEC
• 2004/108/EC
• 2002/95/EC
• 2002/96/EC
EMC
• EN61000-6-4 (Emission)
• EN61000-6-2 (Immunity)
• FCC 47 CFR Part 15 class A (Emission)
• EN 61 000-4-8, L5
Encapsulation
IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety Power supply: EN/UL/IEC 60950-1
Physical data
Camera weight, excl. lens and battery 1.94 kg (4.27 lb.)
Camera weight, incl. lens and excl. battery 2.24 kg (4.94 lb.)
Camera weight, incl. lens and battery 2.48 kg (5.47 lb.)
Battery weight 0.24 kg (0.52 lb.)
Heat shield weight 0.50 kg (1.09 lb.)
Camera size, excl. lens (L × W × H) 284 × 169 × 161 mm (11.2 × 6.7 × 6.3 in.)
Cameras size, incl. lens (L × W × H) 306 × 169 × 161 mm (12.0 × 6.7 × 6.3 in.)
Cameras size, incl. heat shield (L × W × H) 320 × 243 × 195 mm (12.6 × 9.6 × 7.7 in.)
Battery size (L × W × H) 141 × 47 × 28 mm (5.5 × 1.8 × 1.1 in.)
Battery charger size (L × W × H) 158 × 122 × 25 mm (6.2 × 4.8 × 1.0 in.)
Tripod mounting UNC ¼"-20
Housing material Aluminum, magnesium
Grip material
TPE thermoplastic elastomers
#T559157; r. AH/45951/45951; en-US
