Technical data22
Detector data
Detector type Focal plane array (FPA), cooled InSb
Spectral range Built-in cold band pass filter 4.52–4.67 µm
Detector pitch 30 µm
Sensor cooling Stirling Microcooler (FLIR MC-3)
Detects following gases Carbon Monoxide, Nitrous Oxide, Ketene, Ethe-
none, Butyl Isocyanide, Hexyl Isocyanide, Cyano-
gen Bromide, Acetonitrile, Acetyl Cyanide,
Chlorine Isocyanate, Bromine Isocyanate, Methyl
Thiocyanate, Ethyl Thiocyanate, Chlorodimethylsi-
lane, Dichloromethylsilane, Silane, Germane,
Arsine
Electronics and data rate
Full frame rate 60 Hz
Image presentation
Display
Built-in widescreen, 4.3 in. LCD, 800 × 480 pixels
Viewfinder Built-in, tiltable OLED, 800 × 480 pixels
Automatic image adjustment
Continuous/manual; linear or histogram based
Manual image adjustment
Level/span
Image presentation modes
Image modes IR image, visual image, high sensitivity mode
(HSM)
Measurement
Temperature range
–20°C to +300°C (–4°F to +572°F)
Accuracy
±1°C (±1.8°F) or ±1% of reading for temperature
range 0°C to +300°C (+32°F to +572°F)
Measurement analysis
Spotmeter
10
Area
5 boxes with max./min./average
Profile 1 live line (horizontal or vertical)
Difference temperature Delta temperature between measurement func-
tions or reference temperature
Reference temperature Manually set or captured from any measurement
function
Emissivity correction Variable from 0.01 to 1.0 or selected from editable
materials list
Reflected apparent temperature correction Automatic, based on input of reflected temperature
Measurement corrections Reflected temperature, distance, atmospheric
transmission, humidity, external optics
#T559157; r. AH/45951/45951; en-US
198
