3,14in
79,6mm
2,47in
62,7mm
4,36in
110,7mm
Optical axis
1,94in
49,3mm
2,26in
57,5mm
For additional dimensions see page 1
Camera with Lens IR f=23 mm (24°)
Camera with Lens IR f=38 mm (14,5°)
1 2 3 4 5 6 7 8 9 10
1 632 54
A
B
C
D
E
F
G
H
F
C
E
G
D
A
B
Scale
1:2
B
Size
Modified
R&D Thermography
2013-02-18
Basic dimension FLIR GF3xx
T127603
2(5)
A3
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
