FLIR M364C User Manual

Inspectingthethermalcamera
Routinelyinspectthecameraanditsmountingsurfacetoensurethatitisinstalledsecurely,
thatthecoatedsurfacesareintact,andthattherearenosignsofcorrosion.
Whenthecameraispoweredoff,graspitrmlyatthebaseandconrmitisrigidand
secure.Thenholdthecameraabovethebaseandconrmitwillrotatefreelyandwithout
noticeablewobbleorloosenessaroundthepanbearing.
Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthisproductmeetsthestatedstandard(referto
theproduct’sTechnicalSpecication),waterintrusionandsubsequentequipmentfailuremay
occuriftheproductissubjectedtocommercialhigh-pressurewashing.FLIRwillnotwarrant
productssubjectedtohigh-pressurewashing.
Disclaimer
FLIRdoesnotwarrantthatthisproductiserror-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthanFLIR.
FLIRisnotresponsiblefordamagesorinjuriescausedbyyouruseorinabilitytousethe
product,bytheinteractionoftheproductwithproductsmanufacturedbyothers,orbyerrors
ininformationutilizedbytheproductsuppliedbythirdparties.
EMCinstallationguidelines
FLIRequipmentandaccessoriesconformtotheappropriateElectromagneticCompatibility
(EMC)regulations,tominimizeelectromagneticinterferencebetweenequipmentandminimize
theeffectsuchinterferencecouldhaveontheperformanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformanceisnotcompromised.
Note:InareasofextremeEMCinterference,someslightinterferencemaybenoticedon
theproduct.Wherethisoccurstheproductandthesourceoftheinterferenceshouldbe
separatedbyagreaterdistance.
ForoptimumEMCperformancewerecommendthatwhereverpossible:
•FLIRequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingorcablescarryingradiosignalse.g.
VHFradios,cablesandantennas.InthecaseofSSBradios,thedistanceshouldbe
increasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.Aradarbeamcannormallybe
assumedtospread20degreesaboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatusedforenginestart.Thisis
importanttopreventerraticbehavioranddatalosswhichcanoccuriftheenginestart
doesnothaveaseparatebattery.
•FLIRspeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedintheinstallationmanual.
Note:Whereconstraintsontheinstallationpreventanyoftheabove
recommendations,alwaysensurethemaximumpossibleseparationbetweendifferentitems
ofelectricalequipment,toprovidethebestconditionsforEMCperformancethroughout
theinstallation
Importantinformation
11

FLIR M364C Specifications

General

Resolution	640 x 512
Field of View	24° x 18°
Thermal Sensitivity	<50 mK
Pan/Tilt	360° continuous pan, +/- 90° tilt
IP Rating	IP66
Sensor Type	Uncooled VOx Microbolometer
Frame Rate	30 Hz
Spectral Range	7.5 - 13.5 µm
Power Requirements	12-24 VDC
Focus	Automatic
Operating Temperature	-25°C to +55°C
