FLIR M364C User Manual

Note:Thesuppliedgasketprovidesasealbetweentheunitandasuitablyatandstiff
mountingsurfaceorbinnacle.Thegasketshouldbeusedinallinstallations.Itmayalso
benecessarytouseamarine-gradesealantifthemountingsurfaceorbinnacleisnot
entirelyatandstifforhasaroughsurfacenish.
Surfacemountingthekeypad
Surfacemountingprovidesauniforminstallationwheretheproductsprotrude,usuallybythe
thicknessofthebezel,fromthemountingsurface.
1.Checktheselectedlocationfortheunit.Aclear,atareawithsuitableclearancebehind
thepanelisrequired.
2.Beforemodifyingthemountingsurface,refertothedimensionssuppliedinthisdocument
toensurethereisenoughspacefortheunitandallcables.
3.Fixthesuppliedmountingtemplatetotheselectedlocation,usingmaskingorself
adhesivetape.
4.Drill4holesasindicatedonthemountingtemplatetoacceptthexings.
5.Usingasuitableholesaw,makeaholeineachcornerofthecut-outarea.
6.Usingasuitablesaw,cutalongtheinsideedgeofthecut-outline.
7.Ensurethattheunittsintotheremovedareaandthenremoveroughedges.
8.Placethesuppliedgasketontotherearofthekeypad,ensuringthemountingholes
arealigned.
40

FLIR M364C Specifications

General

Resolution	640 x 512
Field of View	24° x 18°
Thermal Sensitivity	<50 mK
Pan/Tilt	360° continuous pan, +/- 90° tilt
IP Rating	IP66
Sensor Type	Uncooled VOx Microbolometer
Frame Rate	30 Hz
Spectral Range	7.5 - 13.5 µm
Power Requirements	12-24 VDC
Focus	Automatic
Operating Temperature	-25°C to +55°C
