FLIR M364C - Fitting the Keypad Mat

9.Connecttherelevantcablestotheunit.
Formoreinformationonttingthecablereferto
10.Secureusingthexingsprovided.
Note:
Theappropriatetighteningtorqueanddrillbitsizetousedependsonthethicknessofthe
mountingsurfaceandthetypeofmaterialitismadefrom.
Note:
Thesuppliedgasketprovidesasealbetweentheunitandasuitablyatandstiffmounting
surfaceorbinnacle.Thegasketshouldbeusedinallinstallations.Itmayalsobe
necessarytouseamarine-gradesealantifthemountingsurfaceorbinnacleisnotentirely
atandstifforhasaroughsurfacenish.
Fittingthekeypadmat
Y oushouldtthekeypadmataftertheunithasbeensecuredtothemountingsurface.
1.Ensurethekeypadmatisorientatedcorrectly.
2.Slidethekeypadmatoverthejoystickandclickitintoplace,startingwithoneofthe
longeredges.
3.Closetheoppositeendofthekeypadmatintothekeypad,ensuringthatthetabslides
intothenotchprovided.Pushallofthetabsonthelongersidesintotheirnotches(you
shouldhearaclickaseachtabengages).
Installation
41
