Videoandnetworkcables
Arangeofcablesissuppledwiththecameratocovertypicalconnectionscenarios.Y ou
mayneedtopurchaseadditionalcablestocompleteyourinstallation.
ConnectorSuitablecables
CompositevideoBNCconnectoron
camera’spowercable
UsethesuppliedBNC-to-BNCvideocable(3m/9.8
ft.),ifnotusingotherwisefortheHD-SDIconnection.
Alternatively,obtaina75–ohmcoaxvideocable
terminatedinBNCconnectorsatbothends.(The
BNCconnectoronthecamera’spowercableisa
femaleconnector).
RayNet(Ethernet)T oconnecttoadevicewithanRJ45socket:
UsethesuppliedRayNet-to-RJ45adaptercable(120
mm/4.7in.).Longeradaptercablesareavailable
separately—referto12.3RayNettoRJ45adapter
cables
T oconnecttoaRaymarineMFDorRayNetnetwork
switch:ObtainasuitablelengthRayNet–to-RayNet
cable(availableseparately—referto12.4RayNetto
RayNetcablesandconnectors).
HD-SDIUsethesuppliedBNC-to-BNCvideocable(3m/9.8
ft.).Ifalongercableisrequired,obtaina75–ohm
coaxvideocableterminatedinBNCconnectorsat
bothends.(TheBNCconnectoronthecamerais
afemaleconnector).
Note:ItisalsopossibletoconnecttoanHDMI-capabledisplayorothervideodevice,
viaasuitablethird-partyHD-SDItoHDMIconverter.Contactyourdealerorretailerfor
suitabledevicesandcables.
4.4NMEA0183connection
NMEA0183devicescanbeconnectedtoyourcamerausingtheNMEA0183wireson
thesuppliedPower/Video/NMEA0183cable.
2NMEA0183portsareavailable:
•Port1:Inputandoutput:4,800baudrateonly.
•Port2:Inputonly:4,800baudrateonly .
Note:
•ForPort1,boththeinputandoutputcommunicateatthesamebaudrate.Forexample,
ifyouhaveoneNMEA0183deviceconnectedtoPort1INPUT,andanotherNMEA0183
deviceconnectedtoPort1OUTPUT,bothNMEAdevicesmustusethesamebaudrate.
Upto4devicescanbeconnectedtothecamera'soutputport,andupto2devicesto
thecamera'sinputports.
Connections49
