IconName
Description
MirroredViewIndicatesthecamerafeedis
reversedagainsttheverticalaxis.
Polarity
Indicatesachangeinimagepolarity.
ColorPalette
Indicatesachangeinimagecolor
palette.
NMEABWSMessage
ReceivingNMEAmessagesusing
BearingandDistancetoWaypoint,
GreatCircle(BWC)sentenceformat
hasbeenenabled;thisisalso
knownasslewtowaypoint.
NMEARSD
ReceivingNMEAmessagesusing
theRadarSystemData(RSD)
sentenceformathasbeenenabled;
thisisalsoknownasradarcursor
tracking.
NMEATTMReceivingNMEAmessagesusing
theNMEATrackedT argetMessage
(TTM)sentenceformathasbeen
enabled;thisisalsoknownas
radartracking.
PowerDownThecameraisshuttingdown.
Cameracontroloptionsandstatusicons
69
