■ save specific frames as infrared images
■ play back the sequence backward and forward
■ set stop and start frames in a sequence to save a part of the sequence
■ choose between looped or linear recording mode
10389703;a2
Figure 10.10 Burst recording toolbar and progress bar
Figure 10.11 Explanations of the Burst recording toolbar
ExplanationCallout
Go to beginning of frame sequence1
Go to previous frame in the frame sequence2
Play back the frame sequence backward3
Stop the recording or the playback of the frame sequence4
Play back the frame sequence forward5
Go to the next frame in the frame sequence6
Go to the end of the frame sequence7
Set start frame for saving of the frame sequence8
Set stop frame for saving of the frame sequence9
10
90 Publ. No. 1557954 Rev. a155 – ENGLISH (EN) – February 7, 2006
10 – Camera program
