FLIR ThermaCAM P65

10.2.5.9 Buttons
10393103;a3
Figure 10.63 Buttons Settings dialog box
Figure 10.64 Explanations of the Buttons Setting dialog box
CommentsValueLabel
Move the joystick left/right to specify the function
of the F1 button on the left side of the camera.
■
None
■
Adjust once
■
Auto focus
■
Reverse palette
■
Next palette
■
Visual/IR
■
Update ref temp
F1
Move the joystick left/right to specify the function
of the F2 button on the left side of the camera.
■
None
■
Adjust once
■
Auto focus
■
Reverse palette
■
Next palette
■
Visual/IR
■
Update ref temp
F2
Move the joystick left/right to specify the function
of the +/- button on the left side of the camera.
■
None
■
Level
■
Span
■
Focus
+/-
For more information about buttons and their functions, see section 9.2 – Keypad
buttons & functions on page 75.
10
Publ. No. 1557954 Rev. a155 – ENGLISH (EN) – February 7, 2006 123
10 – Camera program
