STRADA PAL – MAINTENANCE MANUAL
13/149
The following elements are visible on the maintenance door:
the keyboard card (1),
the screen (2),
the numeric keypad (3),
the contactless antenna (4) (not visible from the inside of the maintenance door),
the coin slot(7)(8),
the position of the payment card slot (6),
the coin bowl (8),
the ticket slot with the key / lock collection interface and optional banknote
slot(5).
Inside of the maintenance door
