STRADA PAL – MAINTENANCE MANUAL
143/149
9. WARNINGS AND FAILURES
9.1 Green warning LED
A green flashing LED is an early warning signal that does not put the parking terminal out
of order. It indicates that an intervention is required, for instance low ticket stock or low
battery charge.
The green warning LED also flashes but slower, to indicate that the terminal is
operational, even if the screen is in screen-saver mode.
Display and cancellation of a warning:
It is possible to view the "DIAGNOSTICS" code in hexadecimal corresponding to a
warning or a failure without opening the maintenance door.
Press simultaneously the "Cancellation" (red) and "Validation" (green) buttons on
the keyboard.
Hold the "Cancellation" button until the "Release change button" message
appears.
Press the "Validation" button as many times as necessary to put the cursor on
the "Errors" function in the menu displayed.
Press the "Cancellation" button to select the function.
The terminal displays the list of the 20 most recent defaults and failures.
You can also open the maintenance door and use the keyboard to select the onsite
programming function 97.
Code
Warning message
Problem
Solution
4003
CHARGING BATTERY
DEFAULT
The voltage of the battery is low
when in operation.
Replace the battery.
4004
IDLE BATTERY DEFAULT
The voltage of the battery is low
when idle.
Replace the battery.
4005
SUPPLY DEFAULT
The voltage of the battery is
insufficient.
Replace the battery.
4100
COIN BOX FAILURE
The number of coins in the coin
box exceeds the limit.
Collect the coins.
4108
PAYMENT BY COINS
DEFAULT
The number of coins in the coin
box exceeds the threshold.
Collect the coins.
4206
TICKET NUMBER BELOW
The number of remaining tickets is
below the threshold set by function
14.
Replace the ticket roll
or modify the
threshold.
After the intervention, use the "DIAGNOSTICS" function to cancel the warning message.
