STRADA PAL – MAINTENANCE MANUAL
68/149
8.2.14 Replacing the banknot bowl
8.2.14.1 Preliminary operations
A. Open the maintenance door
B. Turn off the terminal
8.2.14.2 Replacement
A. Remove the 4 screws (1).
B. Remove the banknote bowl by pulling it outwards.
Replacing the banknote bowl
8.2.14.3 Installation
A. Repeat the previous steps in reverse.
8.2.14.4 End of procedure
A. Turn on the terminal
B. Run a banknote payment test, then cancel it.
C. Close the maintenance door
