Argus E25 MOD II - Operating Instructions
22
Undo the screws (2.19) and remove
the cover (2.6) carefully.
ATTENTION!
The sealing surfaces between
body and cover, and between
cover and shaft are relevant for
flameproof protection.
Damage to these surfaces re-
sults in the loss of flameproof
protection!
Undo the screws (4.22) and remove
the cover plate (cable cover, (4.6)).
The figure on the cover plate (4.6)
shows the standard circuit diagram.
For any other wiring connections,
please contact the manufacturer.
The built-in thermal switch cuts out
when the temperature reaches 120 °C.
