Chapter 2: Instrument Overview
Hyperion Tissue Imager
WARNING Laser instruments generate potentially hazardous UV radiation. Do not
remove the top cover of the Hyperion™ Tissue Imager. Only a Fluidigm field service
engineer should remove the top cover and perform maintenance.
Top cover
Sample window
Wheel retraction
switch
I nt erlo ck L ED pa nel
Lower cover
Coupling tube
Coupling window
AC and
communication panel
Figure 5. Schematic of the Hyperion Tissue Imager side view
