Fluke 1550C User Manual

1550C/1555
Users Manual
24
1
23
GHH06.EPS
Item Description
 Voltage at terminals
 Stored locations
 Stored test results
Figure 11. Viewing Stored Test Data
4. Push  or  to step through the stored locations.
5. Stop at the location you want to view.
6. Push  to view the stored test data for a specific test. Test data appears
on the alphanumeric text display and on the LCD.
7. Push  to call the menu selection.
Download Your Test Results
You can use FlukeView Forms software to download all of your stored test
data to a PC. An infrared adapter is supplied with the Tester for use in
downloading stored test data. Figure 10 shows the location of the IR port on
the Tester.

Fluke 1550C Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	5000 V
AC voltage range	250 - 5000 V
Operating altitude	0 - 2000 m
Overload protection	Yes
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
International Protection (IP) code	IP40
Battery technology	Sealed Lead Acid (VRLA)
Number of batteries supported	1

Weight and Dimensions

Depth	277 mm
Width	269 mm
Height	160 mm
Weight	3700 g
