Fluke 1550C User Manual

Insulation Tester
Measurements
25
1
2
GHH04.EPS
Item Description
 IR Port
 IR Device
Figure 12. IR Port on 1550C/1555 Insulation Tester
Install FlukeView Forms Basic Software
FlukeView Forms Basic software must be installed on your PC to download
stored test data.
To install FlukeView Forms Basic, see the FlukeView Forms Installation
Guide.
To install the infrared adapter, see the USB-IR Cable Installation Guide.

Fluke 1550C Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	5000 V
AC voltage range	250 - 5000 V
Operating altitude	0 - 2000 m
Overload protection	Yes
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
International Protection (IP) code	IP40
Battery technology	Sealed Lead Acid (VRLA)
Number of batteries supported	1

Weight and Dimensions

Depth	277 mm
Width	269 mm
Height	160 mm
Weight	3700 g
