Fluke 1652C User Manual

1652C/1653B/1654B
Users Manual
8
Table 5. Pushbuttons (cont.)
No. Button Description
 
• RCD Current multiplier (x1/2, x1, x5, AUTO).
• Memory STORE.
• Select Loop impedance test accuracy (, m) – hi
current trip mode only
• Continuity test: Rx1/2 (R1+R2), R/2 (R2), x1 (r1), /2 (r2)
or x5 (rn) in extended documentation mode.


• Scroll memory locations.
• Set memory location codes.
• Scroll Auto test results.
• Adjust current for VAR function.
• Display results if noise is present.
 
• Select RCD: Type AC (sinusoidal), Type AC Selective,
Type A (half-wave), Type A Selective, Type B (smooth
DC), or Type B Selective.
• Memory RECALL.
• Battery test.
• Loop R
E
/ I
K
 
• RCD test polarity (0, 180 degrees).
• Insulation test voltage (50, 100, 250, 500, or 1000 V).
• Memory CLEAR.
 
Turns the tester on and off. The tester will also shut off
automatically is there is no activity for 10 minutes.
  Turns the backlight on and off.
 
Starts the selected test.
The  key is surrounded by a “touch pad”. The touch pad
measures the potential between the operator and the
tester’s PE terminal. If you exceed a 100 V threshold, the
 symbol above the touch pad is illuminated.

Fluke 1652C Specifications

General

Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Loop and Line Resistance	0.01 Ω to 2000 Ω
RCD Testing	Yes
Display	Digital
Frequency	45 Hz to 65 Hz
Phase Sequence Indicator	Yes
Power Supply	6 x 1.5 V AA batteries
Weight	1.2 kg
Voltage AC	500 V
Voltage DC	500 V
RCD Trip Current	10 mA, 30 mA, 100 mA, 300 mA, 500 mA
RCD Trip Test	1x
Safety Standards	EN 61010-1
Operating Temperature	-10°C to +50°C
Earth Resistance Test	Not available
