Fluke 1652C User Manual

1652C/1653B/1654B
Users Manual
46
Category Ratings and Usage
Part/Accessory
Printed
CAT Rating
CAT II
250 V
CAT III
500 V
CAT IV
300 V
Electrical Installation Tester CAT III 500 V
CAT IV 300 V
√
√
√
√
√
√
Country-Specific Mains Cord CAT II 250 V
√
Multifunction Probe (red) CAT III 1000 V
√ √ √
Test Lead (red/green/blue) CAT III 1000 V
√ √ √
Test Probe (red/green/blue) CAT III 1000 V
√ √ √
Alligator Clip (red/green/blue) CAT III 1000 V
√ √ √
UK Test Leads and Probes:
Non-fused (red/green/blue)
Fused (red/green/blue)
CAT III 1000 V
CAT III 600 V
√
√
√
√
√
√
Electrical Measurement Specifications
The accuracy specification is defined as ±(% reading +digit counts) at 23 °C ±5 °C, ≤80 %
RH. Between -10 °C and 18 °C and between 28 °C and 40 °C, accuracy specifications
may degrade by 0,1 x (accuracy specification) per °C. The following tables can be used
for the determination of maximum or minimum display values considering maximum
instrument operating uncertainty per EN61557-1, 5.2.4.
Insulation Resistance (R
ISO
)
50 V 100 V 250 V 500 V 1000 V
Limit Value
Maximum
Display Value
Limit Value
Maximum
Display Value
Limit Value
Maximum
Display Value
Limit Value
Maximum
Display Value
Limit Value
Maximum
Display Value
1 1.12 1 1.12 1 1.3 1 1.3 1 1.3
2 2.22 2 2.22 2 2.4 2 2.4 2 2.4
3 3.32 3 3.32 3 3.5 3 3.5 3 3.5
4 4.42 4 4.42 4 4.6 4 4.6 4 4.6
5 5.52 5 5.52 5 5.7 5 5.7 5 5.7
6 6.62 6 6.62 6 6.8 6 6.8 6 6.8
7 7.72 7 7.72 7 7.9 7 7.9 7 7.9
8 8.82 8 8.82 8 9.0 8 9.0 8 9.0
9 9.92 9 9.92 9 10.1 9 10.1 9 10.1
10 11.02 10 11.02 10 11.2 10 11.2 10 11.2
20 22.02 20 22.02 20 22.2 20 22.2 20 22.2
30 33.02 30 33.2 30 33.2 30 33.2 30 33.2
40 44.02 40 44.2 40 44.2 40 44.2 40 44.2

Fluke 1652C Specifications

General

Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Loop and Line Resistance	0.01 Ω to 2000 Ω
RCD Testing	Yes
Display	Digital
Frequency	45 Hz to 65 Hz
Phase Sequence Indicator	Yes
Power Supply	6 x 1.5 V AA batteries
Weight	1.2 kg
Voltage AC	500 V
Voltage DC	500 V
RCD Trip Current	10 mA, 30 mA, 100 mA, 300 mA, 500 mA
RCD Trip Test	1x
Safety Standards	EN 61010-1
Operating Temperature	-10°C to +50°C
Earth Resistance Test	Not available
