Fluke 1652C User Manual

1652C/1653B/1654B
Users Manual
10
24
26
27
25
23
21
22
28
30
39
41
40
31
35
34
33
32
29
38
36
37
apx120f.eps
Figure 4. Model 1654B Display Features
Table 6. Display Features
No. Annunciator Meaning

Displays the selected Memory mode. Memory
modes are: Select (), Store (), Recall
(), or Clear ().

Configuration options. Settings you can make
within the measurement functions. For
example, in the RCD Tripping Time function
(
ΔT) you can press  to multiply the test
current by x1/2, x1, x5 or AUTO and you can
press  to select the type of RCD you are
testing.

Fluke 1652C Specifications

General

Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Loop and Line Resistance	0.01 Ω to 2000 Ω
RCD Testing	Yes
Display	Digital
Frequency	45 Hz to 65 Hz
Phase Sequence Indicator	Yes
Power Supply	6 x 1.5 V AA batteries
Weight	1.2 kg
Voltage AC	500 V
Voltage DC	500 V
RCD Trip Current	10 mA, 30 mA, 100 mA, 300 mA, 500 mA
RCD Trip Test	1x
Safety Standards	EN 61010-1
Operating Temperature	-10°C to +50°C
Earth Resistance Test	Not available
