Fluke 1652C - Tripping Speed Test ( T); Maximum Trip Time

1652C/1653B/1654B
Users Manual
54
Tripping Speed Test (
Δ
T)
RCD Current Selection
Test Function
10 mA 30 mA 100 mA
[1]
300 mA
[1]
500 mA
[1]
1000 mA
[2]
var
[3]
x ½, 1
√ √ √ √ √ √ √
x 5
√ √ √
Ramp
√ √ √ √ √ √ √
Auto
√ √ √
Notes
Mains voltage 100 V – 265 V ac, 50/60 Hz
[1] Type B RCDs require mains voltage range of 195 V – 265 V.
[2] Type AC RCDs only.
[3] Type A RCDs are limited to 700 mA, not available for Type B RCDs.
Measurement Range
Current
Multiplier
*RCD Type
Europe UK
Trip Time Accuracy
x ½ G 310 ms 2000 ms
±(1 % Reading + 1 ms)
x ½ S 510 ms 2000 ms
±(1 % Reading + 1 ms)
x 1 G 310 ms 310 ms
±(1 % Reading + 1 ms)
x 1 S 510 ms 510 ms
±(1 % Reading + 1 ms)
x 5 G 50 ms 50 ms
±(1 % Reading + 1 ms)
x 5 S 160 ms 160 ms
±(1 % Reading + 1 ms)
Notes
*G – General, no delay
*S – Time delay
Maximum Trip Time
The RCD  symbol switches on when testing the RCD trip time if the trip time meets the
following conditions:
RCD I
Δ N
Trip Time Limits
AC G, A, B x 1 Less than 300 ms
AC G-S, A-S, B-S x 1 Between 130 ms and 500 ms
AC G, A, B x 5 Less than 40 ms
AC G-S, A-S, B-S x 5 Between 50 ms and 150 ms
