Miscellaneous
Display
View Area .............. 126.8 x 88.4 mm (4.99 x 3.48 inches)
Resolution............................................... 320 x 240 pixels
Backlight ......................LED (Temperature compensated)
Brightness............................... Power Adapter: 200 cd/m
2
Battery Power: 90 cd/ m
2
Display Auto-OFF time (battery saving) .........30 seconds,
5 minutes or disabled
Power
FLUKE 190-xx4: Rechargeable Li-ion Battery (model
BP291):
Operating Time ................. up to 7 hours (Low Intensity)
Charging Time ................................................... 5 hours
Capacity/Voltage.................................... 52 Wh / 10.8 V
FLUKE 190-xx2: Rechargeable Li-ion Battery (model
BP290):
Operating Time ................. up to 4 hours (Low Intensity)
Charging Time ................................................ 2.5 hours
Capacity/Voltage.................................... 26 Wh / 10.8 V
Rechargeable Li-ion Battery (model BP 290 and BP291):
Life Time (> 80 % capacity)........300x charge/discharge
Allowable ambient
temperature during charging: .....0 to 40 °C (32 to 104 °F)
Auto power down
time (battery saving):..............5 min, 30 min or disabled
Power Adapter BC190:
• BC190/801 European line plug 230 V ±10 %
• BC190/813 North American line plug 120 V ±10 %
• BC190/804 United Kingdom line plug 230 V ±10 %
• BC190/806 Japanese line plug 100 V ±10 %
• BC190/807 Australian line plug 230 V ±10 %
• BC190/808 Universal switchable adapter 115 V ±10 %
or 230 V ±10 %, with plug EN60320-2.2G
Line Frequency .......................................... 50 and 60 Hz
Probe Calibration
Manual pulse adjustment and automatic DC adjustment
with probe check
Generator Output ............................... 1.225 Vpp / 500 Hz
square wave

Fluke 190 Series II Specifications

General

Display	Color LCD
Bandwidth	Up to 200 MHz
Vertical Resolution	8 bits
Maximum Input Voltage	400 V (DC + peak AC)
Vertical Sensitivity	2 mV/div to 10 V/div
Input Channels	2 or 4
Battery Life	4 hours
Connectivity	USB
Input Coupling	AC, DC, GND
Input Impedance	1 MΩ
Operating Temperature	0 °C to +50 °C
Storage Temperature	-20 °C to +60 °C
Power	Li-Ion battery (BP291) or AC adapter
