Fluke 190 Series II User Manual

Introduction
1
Introduction
Warning
Read “Safety Information” before using this
instrument.
The descriptions and instructions in this manual apply to
all ScopeMeter 190 Series II versions (hereafter referred
to as the instrument or as the test tool). The versions are
listed below. The version 190-x04 appears in most
illustrations.
Input C and Input D, and the Input C and Input D selection
keys (
C
and
D
) are only present on the
versions 190-x04.
Version Description
190-062 Two 60 MHz Scope Inputs (BNC),
One Meter Input (banana jacks).
190-102 Two 100 MHz Scope Inputs (BNC),
One Meter Input (banana jacks).
190-104 Four 100 MHz Scope Inputs (BNC)
190-202 Two 200 MHz Scope Inputs (BNC),
One Meter Input (banana jacks).
190-204 Four 200 MHz Scope Inputs (BNC).
190-502 Two 500 MHz Scope Inputs (BNC),
One Meter Input (banana jacks).
