CertiFiber Pro Fiber Optical Loss Test Set
Users Manual
62
GPU118.EPS
Figure 19. Result for Smart Remote Mode (Unsaved Bi-Directional
Results Shown)
 The overall result for the Autotest.
 The fiber IDs and the loss and length measurements for the
fibers:
The result exceeds the limit.
The result is within the limit.
The selected test limit does not have a limit for the test.
D
A
B
C
H
G
E
B
F
