Wireless Network Analyzer
WLAN Card Specifications
25
WLAN Card Specifications
Table 1. Fluke Networks Wireless LAN Adapter Specifications
Standards
Conformity
IEEE 802.11a, b and g
Frequency Range
11a: 4.9~5.925GHz,
11b/g: 2.412~2.484GHz
Type
PC Card 32 bit Card Bus
Media Access
Protocol
IEEE802.11
Modulation
Technique
BPSK / QPSK / 16QAM/
64QAM/, DBPSK/
DQPSK/ CCK
Data Rate (Mbps)
6Mbps to 54Mbps for 11a,
1Mbps to 11Mbps for 11b,
1Mbps to 54Mbps for 11g,
Status LEDs
PWR- powered on
LINK- link status
Security
WEP
: Support 64-bit & 128-bit
encryptions
WPA
Device Drivers
Support Windows 98/ME/
2000/XP
Receiver Sensitivity
(Typically)
-68dBm
@ 54Mbps @11a
-65dBm
@ 54Mbps@11g
-76dBm
@ 54Mbps@11b
Operating
Voltage
DC3.3V
Output Power
(Typically)
13dBm@ 54 Mbps
17dBm@ 11 Mbps
Dimensions
(mm) ±1;
Weight (g)
115mmx 54mm x 7.5mm;
41g
Coverage Area
Indoor 100m
Outdoor 400m
Certification
FCC, CE,
Antenna
Chips antenna
Relative
Humidity
10% to 90%
Temperature
Operating: 0
o
C to 50
o
C
Storage: –20
o
C to 70
o
Warranty
1-year warranty limited
