Fluke VT04 User Manual

Visual IR Thermometer
Menu Functions
15
Table 5 shows the distance to area ratio (D:S) for measurement accuracy.
Table 5. Temperature Measurement Accuracy
AB C
AB C
D
S
For best temperature accuracy,
strive for a full field of view.
hak09.eps
Model D:S A B C
VT02 6:1
38 mm @ 230 mm 60mm @ 360 mm 100 mm @ 600 mm
1.5 in @ 9 in 2.4 in @ 14.5 in 4 in @ 24 in
VT04 9:1
26 mm @ 230 mm 40 mm @ 360 mm 67 mm @ 600 mm
1 in @ 9 in 1.6 in @ 14.5 in 2.7 in @ 24 in
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com

Fluke VT04 Specifications

General

Type	Infrared environment thermometer
Purpose	-
Placement	Hand
Display type	Digital
Product color	Black, Yellow
Display form factor	Rectangular
Accuracy	2 °C
Clock function	Yes
Spectral response	6.5 - 14 µm
Temperature measurement range	-10 - 250 °C
Temperature measurement units	F, °C
Power source	Battery
Battery voltage	3.6 V
Number of batteries supported	1
Certification	EN 61326:2006, IEC/EN 61010-1:2010
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Battery life	8 h

Weight and Dimensions

Depth	55 mm
Width	75 mm
Height	210 mm
Weight	350 g
