Fluke VT04 User Manual

Visual IR Thermometer
Menu Functions
19
Hi/Lo Temperature Alarm (VT04)
High temperature and low temperature alarms are available on the VT04. The
temperature threshold is set for either the high or low alarm. When an alarm is
set, you can quickly scan the scene and find objects that are above or below the
threshold. An alarm condition is clearly shown on the screen as a flashing
red/black band (Hi) or blue/black band (Lo). See Figure 10. In accordance with
the D:S ratio (see Table 5), the object size should be large enough to cover the
area defined by the 4 corner markers.
High Alarm
Low Alarm Measurement Area
hak15.eps
Figure 10. VT04 Hi/Lo Temperature Alarm
Note
The Auto Off feature is disabled in the Alarm mode.
To turn on the alarm:
To turn off the alarm:
To set an alarm:
(-10 °C to +250 °C)
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com

Fluke VT04 Specifications

General

Type	Infrared environment thermometer
Purpose	-
Placement	Hand
Display type	Digital
Product color	Black, Yellow
Display form factor	Rectangular
Accuracy	2 °C
Clock function	Yes
Spectral response	6.5 - 14 µm
Temperature measurement range	-10 - 250 °C
Temperature measurement units	F, °C
Power source	Battery
Battery voltage	3.6 V
Number of batteries supported	1
Certification	EN 61326:2006, IEC/EN 61010-1:2010
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Battery life	8 h

Weight and Dimensions

Depth	55 mm
Width	75 mm
Height	210 mm
Weight	350 g
