4. Peripherals Installation
4-1.
MSR Installation
1. Remove the screws (x2) to release
the MSR dummy cover.
MSR module can be installed to either side of the system. Choose one side and
follow the steps below. Make sure the unit is powered down before starting.
2. Connect MSR cable to the connector
on system side.
3. Insert MSR module in place and
fasten the screws (x2) on the back
to secure the module.
To Next Page
