FlyTech POS485 - Connectors & Functions

27
Connector Function
CN1/CN13/CN21/
CN29
Internal USB connector
CN5 EC Debug
CN6 CPU FAN connector
CN7 LPT connector
CN9 40Pin connector
CN12 SATA power connector
CN18 COM5 (touch) connector
CN19 Wide range power connector
CN25 S0/S5 LED & Power button connector
CN26 51P connector
CN27 eDP connector
CN31 Speaker L output
CN32 Speaker R output
CN33 MIC output
CN34 Earphone connector
BAT1 Battery connector
PWR1/PWR2 DC Jack
RJ11_1 Cash drawer connector
RJ45_1 LAN connector
RJ45_2 COM1/ COM2
RJ48_1 COM3
DDR3_A1 DDR3 SO-DIMM
SATA1/SATA2 SATA connector
USB1/USB2 USB2.0
USB3 USB3.0
VGA1 CRT connector
SW1 Power button
MINI_PCIE1 MINI PCIE
JP6 Cash drawer power setting
