FlyTech POS485 - Connectors & Functions

34
6-4-2.
Connectors & Functions
Connector Function
CN1
System FAN connector
CN2
eDP connector
CN3
HDD power connector
CN4 /8 / 12
USB connector
CN5
MIC-In connector
CN6
Audio connector(right)
CN7
Audio black connector
CN9
M.2 connector
CN10
Power LED connector
CN11
Audio connector(left)
CN13
40 pin external connector
CN14 Printer connector
CN15 Speaker Combo sound connector
CN16 Battery connector
CN17
Power button (internal)
CN18
COM5 connector
CN19
EC Debug
BAT1
Battery connector
PWR1/2
DC Jack
RJ11_1
Cash drawer connector
RJ45_1
LAN connector
RJ48_1
COM3
RJ48_2
COM1/2
USB1/2/5
USB3.0
USB3
USB2.0
VGA1
CRT connector
SW1
Power button
SATA0 /1
SATA connector
DIMM_A1
DDR4 SO-DIMM
BZ1
Buzzer
JP1
Cash drawer power setting
JP2
COMBO speaker setting
