FlyTech POS485 - Connectors & Functions

30
Connector Function
CN1 SATA power connector
CN3 Inverter connector
CN4 LVDS connector
CN5 CPU FAN connector
CN6 System FAN connector
CN7 HDD LED connector
CN8 Speaker & MIC connector
CN9/10 USB port (internal)
CN11 Power LED connector
CN12 40pin external connector
CN13 EC Debug
CN14 Printer connector
CN15 MSR connector
CN16 COM5 (touch) connector
CN17 PS2 keyboard connector
CN18 RTC connector
CN19 Wide Range
CN20 Power button (internal)
CN21 LCM connector
CN22 51pin connector
CN23 SDU connector
CN24 SDU connector (LAN)
RJ45_1 LAN connector
RJ45_2 COM1/ COM2
RJ48_1 COM3
RJ11_1 Cash drawer connector
PWR1 DC Jack (4 pin)
PWR2 DC Jack (2 pin)
SATA0 SATA0
SATA1 SATA1
SW1 Power button
USB1 USB3.0
USB4 USB2.0
USB6 USB2.0
VGA1 CRT connector
DDR3_A DDR3 SO-DIMM
JP1 Inverter select
JP2 Hareware Reset
JP3 Touch connector
JP4 LCD ID setting
JP5 Cash drawer power setting
6-3-2.
Connectors & Functions
