FlyTech POS485 - Connectors & Functions

23
Connector Function
CN1 Front I/O board
CN2 Inverter connector
CN3 LVDS connector
CN6 System FAN connector
CN7 LPT port connector
CN8 Speaker & MIC connector
CN9 40pin external connector
CN10 HDD LED connector
CN11 Power LED connector
CN12 SATA power connector
CN13/14 USB port (internal)
CN15 PS2 keyboard connector
CN17 MSR connector
CN18 COM5 (touch) connector
CN19 Wide Range
CN20 Power button (internal)
CN21 LCM connector
CN22 POS325 51pin connector
CN25 S5/S0 Status LED
PWR1/PWR2 DC Jack
RJ11_1 Cash drawer connector
RJ45_1 LAN connector
RJ45_2 COM1/ COM2
RJ48_1 COM3
DDR3_A1 DDR3 SO-DIMM
SATA0/SATA2 SATA
USB1/USB2 USB2.0
USB3 USB3.0
VGA1 CRT connector
SW1 Power button
MINI_PCIE1 MINI PCIE
JP1 Inverter select
JP4 LCD ID setting
JP6 Cash drawer power setting
JP7 Touch connector
6-1-2.
Connectors & Functions
