REF1/REF2 Compact Refrigerators 25
Hardware
Reference # Description Part #
1 Door with gasket and lock strike bracket, REF1 00953182
1 Door with gasket and lock strike bracket, REF2 00953174
2 Gasket, door, REF1 00960823
2 Gasket, door, REF1 (After Serial H55798) 0118 2724
2 Gasket, door, REF2 00960831
2 Gasket, door, REF2 (After Serial H55798) 0118 2732
3 Hinge, top with spring and hardware 01053677
4 Hinge, bottom 00940478
Not shown Hinge kit, top and bottom with hardware 01053685
5 Spring bolt lock 01065507
6 Spring bolt with latch, bracket, and hardware 01081702
7 Lock, deadbolt with keys 00959528
8 Bracket, lock mounting 01095843
9 Panel, front 01081660
Not shown PR Models only -panel, front, REF1/2 0115710 6
Not shown Slide out condensate assy, REF1/2 - PR Models 01157114
Not shown Panel, front with keypad 01081678
10 Battery pack 01085018
Not shown Foot pads 00900134
11 Screws, front panel (2 required) 203460
12 Strip sealer, REF1/2, /FZR1/2 01081736
Not shown Fascia heater, REF1 01064641
Not shown Fascia heater, REF2 01064666
13 Shelf 00969956
14 Bracket, lock strike 01041953
15 Display, controller 01085794
Not shown Bracket, bottle 00961656
Not shown Bottle, solution, 60 mL 00112037
Not shown Gasket, bottle 0012029
16 Reed switch 01092048
Not shown Pilaster, screw 206796
Not shown Pilaster 00961334
Not shown Support, shelf 00156240
