REF1/REF2 Compact Refrigerators 27
Compressor Components
1
2
3
4
5
6
9
7
8
Reference Description Part #
1 Compressor, REF1 and REF2 (includes 00959510, 00961631, 00997959) 01053529
2 Bracket, Compressor Support, REF1 and REF2 00958694
3 Switch, Rocker, Recessed 00967604
4 Capillary Tube, REF1 and REF2 00959510
5 Filter/Drier 00961631
6 Coil, Evaporator/Condenser, REF1 and REF2 00939835
7 Baffle, Air 00965814
8 Shroud, Condenser Fan, REF1 and REF2 01128438
9 Motor, Fan 00940460
Not shown Cord, Power, NEMA 5-15 Hospital Grade 00961268
Not shown PTC Starting Device, Compressor 00997957
